A Web Chat widget that is visible in configuration but does not load on the company website commonly points to an asset-domain mismatch. Cisco Webex Connect live chat assets require the website domain to be configured for the asset so the platform can validate where the widget is embedded. The exhibit shows the browser-side failure after widget code is implemented, which is consistent with the site domain not matching the domain configured for the Web Chat Asset. Missing Webex Connect flow configuration usually causes chat handling or routing failures after a chat is initiated, not the widget failing to load. A firewall block to a widget domain is possible in the real world, but the question says the engineer sees output in the browser while investigating Webex Contact Center, and the Cisco configuration control involved is the website domain on the asset. Content Security Policy allow-listing in Webex Contact Center is for desktop/embedded content behavior, not the primary asset-domain validation for web chat loading. Reference: Webex Connect Help, Livechat; Cisco Help, Set up digital channels in Webex Contact Center.

A Scheduled Callback activity must know when the callback should occur and the timezone in which that schedule should be interpreted. Cisco's callback scheduling API and Webex Connect scheduling behavior use normalized date/time inputs so a callback is created at the expected customer time. The date format in the answer set is YYYY-MM-DD, which is the standard year-month-day format used by modern APIs and scheduling fields. The timezone is required because the same date and time can represent different UTC instants depending on the caller's or business's region. Customer name and phone ANI may be useful data in a broader callback workflow, but they are not the two key values asked here for configuring the Scheduled Callback node successfully. The YYYY-DD-MM format is not the accepted ordering and would create ambiguous or invalid schedules. The correct pair is therefore schedule date in YYYY-MM-DD format and schedule timezone. Reference: Webex Developer, Callback Schedule API; Webex Connect Help, Event Scheduler and scheduled flow activities.

The least privileged role that satisfies both capabilities is Supervisor. The user must participate in telephone campaigns and must also speak to an agent without the customer hearing, which is supervisor whisper coaching. Standard and Premium Agent roles can handle assigned interactions based on license capabilities, but they do not provide supervisory monitoring, whisper coaching, barge-in, or team oversight controls. An Administrator role would provide much broader configuration authority than needed, violating the least-privilege requirement. Cisco's Contact Center licensing and role model separates agent capabilities from supervisor capabilities; Premium Agent adds additional digital and reporting capabilities, while Supervisor adds monitoring and assistance functions. Whisper coaching is specifically a supervisor call-monitoring function, not a standard agent function. Because the scenario does not require tenant configuration, user provisioning, routing setup, or recording policy administration, Administrator is excessive. Supervisor is the minimal role that gives the monitoring feature while also supporting campaign participation. Reference: Cisco Help, Manage access in Webex Contact Center; Webex Contact Center Data Sheet.

For PSTN calls arriving at Webex Contact Center, the safe media statement is that the supported voice codecs are G.711 mu-law and G.711 A-law. Cisco's Webex Contact Center telephony material emphasizes PSTN and Local Gateway interoperability through standard SIP media, and the exam objective expects knowledge of codec compatibility at the service edge. Opus is widely used in WebRTC and collaboration media contexts, but it is not natively supported for PSTN ingress into Webex Contact Center without appropriate interworking or transcoding in the overall design. SIP early media support also must not be assumed as fully supported in every Webex Contact Center call path. DTMF handling is important, but the option saying it can use out-of-band is not the most accurate description of the PSTN media requirement in this question. The codec restriction is the definitive media requirement and is why option B is correct. Reference: Cisco Help, Set up voice channels for Webex Contact Center; Webex Contact Center architecture and telephony documentation.

The registration refresh interval is derived from the expires value multiplied by the refresh ratio. In Cisco IOS XE Local Gateway configuration for Webex Calling, the registrar command commonly uses an expires value and a refresh-ratio. With expires 240 and refresh-ratio 50, the gateway refreshes registration at 50 percent of 240 seconds, which is 120 seconds, or exactly two minutes. Option B uses refresh-time, which is not the documented parameter used in the provided command style. Option C would refresh at 60 seconds because 50 percent of 120 is 60. Option D would refresh at 150 seconds because 50 percent of 300 is 150. The correct answer is therefore the command that sets expires to 240 with refresh-ratio 50 over TLS using the sips scheme. This aligns with Cisco's registration-based Local Gateway model, where the SBC must keep SIP registration active toward Webex Calling. Reference: Cisco Help, Configure Local Gateway on Cisco IOS XE for Webex Calling; Configure trunks, route groups, and dial plans for Webex Calling.

Webex App state synchronization is configured under the Desktop > Webex App configuration area, where the administrator enables Webex App integration, enables state synchronization, and maps Webex availability states to Webex Contact Center idle codes. The requested behavior is specific: when an agent is on a non-contact-center Webex App call, Agent Desktop must move to the configured WebexAppCall idle state. Cisco's documentation identifies the Webex availability state as On a Call for this situation, not Outgoing Call. Therefore, On a Call must be mapped to the WebexAppCall idle code. The idle code must already exist in Webex Contact Center; it does not need to be added to a desktop layout, because idle codes are assigned through desktop profile configuration rather than layout JSON. The option that places state synchronization under Collaboration in the desktop profile does not match the stated Control Hub path. The three required actions are enabling the Webex App integration, mapping On a Call, and enabling State Synchronization. Reference: Cisco Help, Manage desktop profiles; Integrate Webex Contact Center CRM Connector for Microsoft Dynamics 365, state synchronization section.

A reorder tone followed by call drop at call ingress is usually a telephony signaling or trunk acceptance symptom, not an Analyzer or queue-configuration symptom. In a Bring Your Own PSTN design, the customer's PSTN carrier and session border controller are responsible for delivering calls toward Webex Contact Center through the agreed voice path. Cisco's Webex Calling and Local Gateway documentation emphasizes trunk status, SIP connectivity, registration or certificate state, and SBC reachability as the first checks when calls fail before application routing. If the call cannot be successfully established across the customer's SBC or Local Gateway, Webex Contact Center will not have a usable interaction to queue, analyze, or route. Analyzer becomes useful after the platform has received enough call data to create records; it is not the first place to diagnose a reorder tone at ingress. Channel and queue association should still be reviewed later, but the symptom points first to SIP trunk status on the SBC. Reference: Cisco Help, Get started with Local Gateway; Configure trunks, route groups, and dial plans for Webex Calling.

userId: $.data.users[?(@.phoneNumber == '+1 (555) 123-4567')].userId

currentPage: $.data.currentPage

The JSONPath mapping must match the structure shown in the API response. The userId variable is not a simple top-level property; it sits inside the users array. The expression must filter the users array for the object whose phoneNumber equals +1 (555) 123-4567 and then return that object's userId. That is why the filtered JSONPath expression using $.data.users[?(@.phoneNumber == '+1 (555) 123-4567')].userId is the correct mapping. The currentPage variable is directly under data, so the correct expression is $.data.currentPage. Expressions such as $.currentPage miss the data wrapper, and $.data.currentPage.number assumes currentPage is an object with a number property, which the response does not show. $.data.user[0] .userId is also wrong because the array name in the response is users, not user, and it would take the first user rather than the matching phone number. Reference: Webex Connect Help, Custom Node Integration; Webex Connect flow data parsing guidance.
