By default, Huawei firewalls create security zones such as Trust, Untrust, and Local. The DMZ (Demilitarized Zone) is a security zone explicitly created by users. A DMZ is used to isolate an internal network from the external one, providing an additional layer of security by placing public-facing services (e.g., web servers) in this intermediary zone. This setup ensures that if a public-facing service is compromised, the internal network remains secure. Huawei Firewall configuration steps confirm this zoning principle, making DMZ creation an explicit user-driven action ​.

After Layer 3 roaming, the STA’s traffic is forwarded from the Foreign AP (FAP) to the Foreign AC (FAC), and then to the Home AC (HAC) before reaching the upper-layer network. This ensures that the STA remains on the same subnet without breaking existing sessions ​.

Comprehensive and Detailed Step-by-Step Explanation:

1. What is a Firewall Session?

A firewall session is an entry used to maintain the connection state of a protocol.

When a packet is forwarded, the firewall creates a session for it and tracks subsequent packets for the same connection to ensure efficient forwarding and security enforcement.

2. Analysis of Each Option:

Option A: Subsequent fragment

Incorrect.

A session is created for the initial fragment of a packet. Subsequent fragments are matched to the existing session and do not trigger the creation of a new session.

Option B: ICMP error packet

Incorrect.

ICMP error packets (e.g., Destination Unreachable) are considered exceptions and do not create new sessions.

Option C: GRE (Generic Routing Encapsulation)

Correct.

GRE is a tunneling protocol that encapsulates packets. A firewall creates a session for GRE traffic to track the state of the encapsulated connection.

Option D: TCP (Transmission Control Protocol)

Correct.

TCP is a connection-oriented protocol, and firewalls create sessions for TCP connections to track their state (e.g., SYN, SYN-ACK, FIN).

3. Summary:

The firewall creates sessions for GRE and TCP protocols.

When configuring VRRP, the virtual router priority and virtual IP address are mandatory because they define the VRRP instance and its role within the group. Preemption mode and preemption delay are optional configurations that influence how routers take over the master role when priorities change. These are not mandatory for the VRRP protocol to function ​.

Option A is false . When advertising a route to an IBGP peer, the BGP speaker does not modify the AS_Path. It simply advertises the route as-is , preserving the AS_Path learned from EBGP.

Clarification of the options:

B is correct: When a route is sent to an EBGP peer, the local AS is prepended to the AS_Path.

C is correct: The AS_Path begins with the local AS when a new route is advertised to an EBGP neighbor.

D is correct: IBGP does not modify AS_Path when passing routes within the same AS.

Reference from Huawei HCIP-Datacom-Core Technology Study Guide:

“BGP speakers prepend their AS number to the AS_Path only when advertising to EBGP peers. IBGP peers do not alter the AS_Path.”

(Chapter: BGP Path Attributes – Section: AS_Path)

In a route-policy, attributes such as MED (Multi-Exit Discriminator) and Local-Preference can be used in apply clauses to influence BGP route selection. Attributes like AS_Path and Tag are typically matched or filtered but not directly applied in the apply clause ​.

Comprehensive and Detailed In-Depth Explanation:

IPsec (IP Security Protocol) establishes Security Associations (SAs) for encrypted communication.

An SA is uniquely identified by a 3-tuple :

SPI (Security Parameter Index) → Identifies the SA.

Destination IP Address → Specifies the receiving device.

Security Protocol ID → Indicates whether AH (Authentication Header) or ESP (Encapsulating Security Payload) is used.

A. Key exchange protocol is not part of the SA 3-tuple . It is used during IKE (Internet Key Exchange) but is not part of the SA itself.

???? Reference: Huawei HCIA-Datacom Study Guide, IPsec Security Association and SA Identification.

 IS-IS Overview : Intermediate System to Intermediate System (IS-IS) is a link-state routing protocol. Routers exchange Link State Packets (LSPs) to maintain a synchronized link-state database. These LSPs are categorized into Level-1 LSPs (intra-area routing) and Level-2 LSPs (inter-area routing). Both types share the same packet format.
