The distance between the project site and the manufacturing location is determined by the straight line distance.  This is because the LEED V5 Reference Guide for Building Design and Construction states that the distance should be measured as the crow flies 1 . The straight line distance is the shortest distance between two points on a plane, regardless of the mode of transportation or the road conditions. The image that you sent shows the straight line distance between the project site and the manufacturing location as the line segment AB.

Source control is one of the control measures recommended by the Sheet Metal and Air Conditioning National Contractors Association (SMACNA) for the Indoor Environmental Quality Credit, Construction Indoor Air Quality Management Plan. Source control means minimizing the generation and emission of indoor air pollutants from the construction activities and materials. Some examples of source control are1:

• Using low-emitting adhesives, sealants, paints, coatings, and flooring systems that comply with the VOC limits of the applicable LEED credit.

• Storing absorptive materials in a protected area and covering them with plastic sheeting to prevent moisture and mold growth.

• Scheduling the installation of finish materials after the completion of wet and dusty work, such as concrete pouring, drywall sanding, and painting.

• Isolating work areas where high levels of contaminants are generated or used, such as welding, cutting, grinding, and solvent cleaning, and providing adequate ventilation and exhaust.

• Prohibiting smoking, eating, and drinking in the work areas, and providing designated areas for these activities.

For LEED BD+C Location and Transportation (LT) Credit: Surrounding Density and Diverse Uses , Option 1: Surrounding Density , the project team must measure:

Residential density in dwelling units per acre (DU/acre) or dwelling units per hectare (DU/ha).

Non-residential density based on floor area ratio (FAR) .

The density must be measured within a ¼-mile (0.40 km) radius of the project boundary.

This credit promotes high-density development and reduces urban sprawl , thereby improving access to amenities and public transportation.

(Source: Official LEED BD+C Reference Manual)

The correct answer is D. Document total waste per building floor area.

According to the LEED V5 .1 Reference Guide for Building Design and Construction, Option 2 of the Construction and Demolition Waste Management credit requires projects to reduce the total construction waste generated by the project to less than 12.2 kilograms per square meter (2.5 pounds per square foot) of the building’s floor area 1 . This option rewards projects for implementing waste prevention strategies, such as designing for material optimization, prefabrication, modular construction, deconstruction, and reuse 1 . To meet the requirements of this option, projects must document the total weight or volume of all construction waste generated by the project, excluding land-clearing debris and excavated soil, and divide it by the building’s floor area 1 . Projects must also provide a narrative describing the waste prevention measures taken during design and construction 1 .

Showers are addressed under Water Efficiency (WE) Prerequisite: Indoor Water Use Reduction and Location and Transportation (LT) Credit: Bicycle Facilities . Showers in indoor water use reduction help minimize potable water consumption, while in the Bicycle Facilities credit, they support cycling commuters by providing end-of-trip facilities. The other options refer to credits or prerequisites unrelated to shower facilities.

An energy meter must be installed for hot water at the main service point for the project to meet the requirements for Energy and Atmosphere Prerequisite, Building-Level Energy Metering. According to the LEED V5 BD+C Reference Guide, this prerequisite requires that “all energy sources used by the building must be metered or submetered” 1 . The hot water from the central utility plant is an energy source used by the building, even if it is not directly paid by the office. Therefore, it must be metered at the point where it enters the building. The other options are incorrect because natural gas is not an energy source used by the building in this case, and the flat fee or the ownership of the energy source do not exempt the project from the metering requirement.

For the Materials and Resources Credit, Building Life-Cycle Impact Reduction, Option 2. Renovation of Abandoned or Blighted Buildings, up to 25% of the building surface area may be excluded from the credit calculation due to deterioration or damage 1 .

This option requires the project team to focus on reducing the water consumption of the school project, because it is located in a basin that depends on the seasonal snowmelt for its water supply 1 .  Installing efficient plumbing fixtures, such as low-flow faucets, toilets, and showerheads, can help save water and reduce the demand on the local water resources 2 .  This option can also help the project achieve the LEED credits for outdoor and indoor water use reduction 3 .

To comply with Indoor Environmental Quality Credit, Interior Lighting, Option 1. Lighting Control, the tenant of a new office building will require 93 lighting control devices with at least three lighting levels per floor. This is because the credit requires that at least 90% of individual occupant spaces have lighting controls that enable occupants to adjust the lighting to suit their individual tasks and preferences 1 . The credit also requires that all shared multioccupant spaces have lighting controls that enable adjustments that meet the needs of the group 1 . According to the LEED BD+C Reference Guide, an individual occupant space is defined as an enclosed space or an open space that is occupied by one person and is at least 50 square feet (4.6 square meters) in area 1 . A shared multioccupant space is defined as an enclosed or open space that is occupied by more than one person and is at least 100 square feet (9.3 square meters) in area 1 .

Based on the given information, each workstation can be considered as an individual occupant space, and each bathroom facility and conference room can be considered as a shared multioccupant space. Therefore, the number of lighting control devices per floor can be calculated as follows:

For the 100 workstations, 90% of them need lighting controls, which is 90 workstations. Each workstation needs one lighting control device, so the total number of lighting control devices for the workstations is 90.

For the two bathroom facilities, each facility needs one lighting control device, so the total number of lighting control devices for the bathroom facilities is 2.

For the one conference room, one lighting control device is needed, so the total number of lighting control devices for the conference room is 1.

The total number of lighting control devices per floor is then 90 + 2 + 1 = 93 .

The Owner’s Project Requirements (OPR) is the document that should be used to record the project goals to be used throughout the design of the project. The OPR is a written document that details the ideas, concepts, and criteria that are determined by the owner to be important to the success of the project1. The OPR is developed during the pre-design phase and is used as a basis for the design team to prepare the Basis of Design (BOD), which describes how the design of the building systems meets the OPR2. The OPR is also used to evaluate the design, construction, and commissioning of the project to ensure that the owner’s expectations are met3.
