Easy Virtual Network is the best fit when a campus needs many Layer 3 virtual networks with separate addressing and routing tables but wants lower operational overhead than manually configuring VRF-Lite everywhere. EVN builds on VRF concepts and simplifies virtualization across a hop-by-hop campus design by reducing repetitive configuration and enabling consistent virtual network transport across participating devices. Each virtual network maintains its own routing context, which supports overlapping addressing and segmentation. Hop-by-hop VRF-Lite can provide similar forwarding separation, but it becomes operationally heavy as the number of VRFs grows because each trunk, routing process, and interface association must be configured and maintained manually. Multihop MPLS can scale, but it introduces provider-style complexity and may require features or skills beyond a typical campus requirement. Multihop IPsec tunneling is not an efficient campus segmentation solution for hundreds of virtual networks. Therefore, EVN is the recommended design for scalable Layer 3 virtualization with simpler configuration and management. Reference topics: campus virtualization, Easy Virtual Network, VRF separation, scalable virtual networks, route isolation.

MSTP is the correct spanning-tree choice for a Layer 2 design with many logical ports, multiple trunked VLANs, and a subsecond convergence requirement. Rapid PVST+ provides rapid convergence, but it creates a separate spanning-tree instance for every VLAN. With 30 VLANs on trunks and hundreds of active ports, the number of logical STP ports can grow quickly and increase CPU and memory load. MSTP maps many VLANs into a smaller number of spanning-tree instances while still using rapid convergence behavior based on IEEE 802.1w principles. This makes it more scalable for large Layer 2 domains than PVST+ or Rapid PVST+ when many VLANs are present. CST provides a single instance but lacks the flexibility and convergence characteristics expected in modern enterprise designs. The design needs both scalability and fast convergence, and MSTP is the standards-based protocol that best satisfies both requirements. Reference topics: MSTP, Rapid STP, logical STP ports, VLAN-to-instance mapping, Layer 2 scalability, convergence.

The correct design uses IPv4 unicast for Company A and Company B and VPNv4 in the shared core. In an MPLS Layer 3 VPN architecture, customer edge routing toward the provider edge commonly uses the ordinary IPv4 unicast address family. The PE router then places the learned customer routes into the appropriate VRF. Across the shared provider core, MP-BGP carries those customer routes as VPNv4 prefixes by adding route distinguishers, which keep identical or overlapping customer prefixes unique. Route targets then control which VRFs import or export each route. Cisco describes this VRF and VPNv4 model as the mechanism that prevents one VPN customer from learning another customer’s prefixes while sharing the same provider backbone. VPNv4 is not normally used directly between the customer networks and their CE-facing sessions. Therefore, the customer sides use IPv4 unicast, and the shared core uses VPNv4 to preserve separation. Reference topics: MPLS Layer 3 VPN, MP-BGP VPNv4, VRF, route distinguisher, route targets, customer route isolation.

NETCONF supports event notifications through a subscription model. The operation used to establish a notification subscription is create-subscription. When a client sends this operation, it can specify the stream and optional filters that determine which notifications are delivered to that NETCONF session. This is why create-subscription is the operation associated with session-specific notification filtering. The commit operation is used with the candidate configuration datastore to apply configuration changes to the running datastore; it does not create a telemetry or event subscription. The notification element is the message sent by the server after a subscription exists, not the operation used to create one. Logging is not a NETCONF operation in the protocol operation set. In Cisco model-driven management designs, NETCONF provides structured configuration and operational access using YANG data models, while notifications allow the management station to consume specific events without relying on repeated screen scraping or broad polling. Therefore, the correct operation for creating filtering specific to session notifications is create-subscription.

The correct EIGRP design consideration is to prevent unnecessary neighborships from forming across switch virtual interfaces. In a data center or campus switching environment, many SVIs may exist for VLAN default gateways, but those VLANs do not necessarily need EIGRP adjacencies with attached hosts, firewalls, load balancers, or peer switches. Cisco EIGRP design commonly uses passive-interface behavior to advertise connected networks while suppressing EIGRP hello packets on interfaces where neighbor relationships are not required. This reduces control-plane noise, minimizes accidental adjacencies, and limits the failure domain. Manual summarization is useful at hierarchy boundaries, but performing summarization on all Layer 3 interfaces can create black holes or hide topology detail where it is still needed. Lowering hello and hold timers to minimum values can increase CPU load and is not the primary design recommendation. Multiple EIGRP autonomous systems may be used for specific segmentation designs, but they add redistribution and operational complexity. Therefore, preventing unnecessary EIGRP neighborships across SVIs is the best design practice from the choices.

Making R3 an L1/L2 router restores the required IS-IS hierarchy and prevents the outage caused by the failed R1-to-R2 link. In IS-IS, Level 1 routers have detailed topology only inside their own area, while Level 2 routers provide the interarea backbone. Routers that connect a Level 1 area to the Level 2 backbone must operate as Level 1/Level 2 devices so they can participate in both databases and provide an exit path for area traffic. If a path between areas depends on a router that is only Level 1 or only Level 2 in the wrong location, traffic can be blackholed when a key link fails. Configuring R3 as L1/L2 gives the topology an additional valid transition point between the local area and the backbone, improving continuity after the R1-to-R2 failure. Making unrelated routers L1 or L2 does not necessarily create the required interarea attachment. Reference topics: IS-IS Level 1, Level 2 backbone, L1/L2 routers, interarea reachability, hierarchical IGP design.

The Cisco SD-Access fabric data plane leverages VXLAN-style MAC-in-IP encapsulation to transport endpoint traffic across the Layer 3 fabric. In SD-Access, the underlay provides IP reachability between fabric nodes, while the overlay uses encapsulation to carry user traffic and policy context across that underlay. Cisco fabric edge nodes encapsulate traffic before forwarding it through intermediate nodes and decapsulate it when it reaches the destination edge or border. LISP is used by the control plane to resolve endpoint-to-location mappings, so option A describes the mapping function rather than the data plane. IS-IS provides underlay routing reachability and is not the overlay data-plane mechanism. BGP can be used outside the fabric or in other overlay designs, but it is not the SD-Access fabric data plane. The exam option describes the essential encapsulation function, even though VXLAN is technically MAC-in-UDP over IP. Reference topics: SD-Access data plane, VXLAN encapsulation, fabric edge forwarding, underlay and overlay separation, policy transport.

Secure segmentation is the Cisco SD-WAN Secure Direct Cloud Access function that separates user traffic into different zones and VPNs or VRFs. In Cisco SD-WAN, VPNs provide logical segmentation that is comparable to VRF separation in traditional routing. Secure Direct Cloud Access extends this segmentation model when users access internet and cloud applications directly from the branch. The design can keep corporate, guest, payment, voice, IoT, and other traffic classes isolated, with policy and security controls applied per segment or zone. Centralized data policy controls forwarding behavior, but the feature that divides traffic into separate zones and VPN or VRF contexts is secure segmentation. Perimeter control and application-aware routing are useful security and performance functions, but they do not describe the core segmentation mechanism. Segmentation is a fundamental SD-WAN design requirement because direct cloud access must not collapse trust boundaries simply because traffic no longer hairpins through a central data center. Reference topics: Cisco SD-WAN secure segmentation, VPNs, VRFs, direct cloud access, zone-based policy.

Scalable groups provide intra-VN traffic filtering and control in Cisco SD-Access. Within a virtual network, macro segmentation separates routing tables, but endpoints inside the same VN may still need policy control based on identity, role, or security posture. Cisco SD-Access uses scalable group tags and scalable group ACLs to implement group-based policy. This allows policy to be expressed as user or device group relationships instead of only subnet-based ACL entries. The result is microsegmentation inside the virtual network, where traffic between groups can be permitted or denied consistently across the fabric. MAC ACLs are limited Layer 2 filters and do not provide the identity-based policy model required for SD-Access. Prefix lists are route-filtering tools, not intra-VN access-control mechanisms. Service policies are used for QoS or traffic treatment and do not define group-based segmentation. Scalable groups are therefore the correct policy construct for intra-VN filtering in the fabric. Reference topics: Cisco SD-Access policy, scalable groups, SGT, SGACL, microsegmentation, intra-VN control.

The multicast-replicator function is used to optimize multicast traffic distribution across Cisco SD-WAN. Cisco Catalyst SD-WAN multicast overlay design avoids forcing the ingress WAN Edge router to replicate every multicast packet to every remote receiver. Instead, multicast routes and receiver information are exchanged through OMP, and a WAN Edge can be designated as a multicast or OMP replicator. The replicator then distributes streams to interested receivers across the overlay, reducing bandwidth and processing pressure on the source-side edge. That is why multicast-replicator is the feature that optimizes WAN bandwidth for IGMP-driven multicast receiver traffic among WAN Edge routers in the same VPN. IGMPv2 is only the host-to-router group membership protocol and does not optimize overlay distribution by itself. A multicast RP is used in PIM sparse mode, but it is not the SD-WAN overlay replication feature. Multicast service routes advertise multicast service information, but the bandwidth-saving forwarding role is the replicator. Reference topics: Cisco SD-WAN multicast overlay, OMP multicast routes, multicast replicator, IGMP receiver joins.
